WLL |
a |
b |
c |
d |
e |
f |
g |
h |
i |
weight |
stock no. |
| (t) |
(mm) |
(mm) |
(mm) |
(mm) |
(mm) |
(mm) |
(mm) |
(mm) |
(mm) |
(kg) |
|
| 2,00 |
13,5 |
16 |
34,0 |
13,0 |
22,0 |
43,0 |
81 |
82 |
13 |
0,39 |
1070147 |
| 3,25 |
16,0 |
19 |
40,0 |
16,0 |
27,0 |
51,0 |
97 |
98 |
17 |
0,67 |
1070148 |
| 4,75 |
19,0 |
22 |
46,0 |
19,0 |
31,0 |
59,0 |
112 |
114 |
19 |
1,08 |
1070149 |
| 6,50 |
22,0 |
25 |
52,0 |
22,0 |
36,0 |
73,0 |
134 |
130 |
22 |
1,66 |
1070150 |
| 8,50 |
25,0 |
28 |
59,0 |
25,0 |
43,0 |
85,0 |
154 |
150 |
25 |
2,46 |
1070151 |
| 9,50 |
28,0 |
32 |
66,0 |
28,0 |
47,0 |
90,0 |
167 |
166 |
27 |
3,40 |
1070152 |
| 12,00 |
32,0 |
35 |
72,0 |
32,0 |
51,0 |
94,0 |
180 |
178 |
30 |
4,51 |
1070153 |
| 13,50 |
35,0 |
38 |
80,0 |
35,0 |
57,0 |
115,0 |
209 |
197 |
33 |
6,10 |
1070154 |
| 17,00 |
38,0 |
42 |
88,0 |
38,0 |
60,0 |
127,0 |
230 |
202 |
19 |
7,63 |
1070155 |
| 25,00 |
45,0 |
50 |
103,0 |
45,0 |
74,0 |
149,0 |
271 |
249 |
23 |
13,25 |
1070156 |
| 35,00 |
50,0 |
57 |
111,0 |
50,0 |
83,0 |
171,0 |
305 |
269 |
26 |
18,53 |
1070157 |
| 42,50 |
57,0 |
65 |
130,0 |
57,0 |
95,0 |
190,0 |
345 |
301 |
29 |
25,94 |
1070158 |
| 55,00 |
65,0 |
70 |
145,0 |
65,0 |
105,0 |
203,0 |
376 |
330 |
32 |
35,33 |
1070159 |
| 85,00 |
75,0 |
83 |
162 |
73,0 |
127,0 |
229,0 |
427 |
380 |
39 |
52,97 |
1070160 |
| Material |
Bow and pin high tensile steel, Grade 6, tempered |
| safety factor: |
MBL = 6-fold WLL |
| standards: |
EN 13889 and meets the performance requirements of US Fed. Spec. RR-C-271
Typ IVA Class 3, Grade A |
| surface treatment: |
galvanized |
| Operating temperature range: |
-20 °C bis + 200 °C |
|
